GARÁŽOVÉ BRÁNY prestige

FOR HEATED BUILDINGS

FOR DAMP PREMISES

FOR REGIONS WITH COLD CLIMATE


  • Panely s hrúbkou 45 mm
  • Double rollers
  • Components from galvanized steel
  • Two-wing EPDM-seals
  • Up to 25 000 open/close cycles
  • Up to 25 000 open/close cycles
  • Torsion shaft fixing click-system
  • 5 typov panelov na výber
  • Up to 10 standard RAL-colors and 3 woodgrain finishes
  • Application of custom-made patterns of any complexity on the door leaf

High quality door leaf for years to come

  • Closed-circuit construction

    Special connection of internal and external steel sheets protects the panel from delamination under the sun. The leaves are connected at the top and at the bottom in 4 layers with the self-tapping screws. So the customers ordering dark-colored doors can rely on their durability.
  • Protection against finger trapping

    Alutech panels comply with one of the main European safety standards: they avoid finger trapping (comply with EN12604).
  • Good adhesion of steel sheets and foam

    Adhesive lacquer coating (of 12 microns) ensures good adhesion of steel sheets and foam. So the design engineers have eliminated bubbling of the panel under the sun.
  • Perfect anticorrosion properties

    Primer layer (of 14-16 microns) and zinc coating (of 16 microns) ensures perfect anticorrosion properties.
  • Durable coating

    Polyurethane coating with integrated polyamide particles (PUR-PA) that enhance anticorrosion and protection properties of the panel allow to save attractive original appearance of the door leaf.
  • Efficient thermal insulation

    Efficient thermal insulation. The reduced thermal transmission resistance of Alutech panels is 1.05 m2°C/W. It is equal to that of a red brick wall 60 cm thick.

Design of a 45 mm sandwich panel

Microwave

  • 10 standard colours with Woodgrain embossing
  • It is possible to paint in any colour according to RAL and DB catalogues.
  • 13 wood-finished colours - digital printing
  • 5 stone-finished colours - digital printing
  • Individual image of the photo on the door leaf according to the sketches of the customer – digital printing
Sepia brown, close to RAL 8014
Desert Oak
Red brick

S-ribbed

  • 10 standard colours with Woodgrain embossing
  • 3 colors imitating wood grain with smooth surface
  • It is possible to paint in any colour according to RAL and DB catalogues.
  • 13 wood-finished colours - digital printing
  • 5 stone-finished colours - digital printing
  • Individual image of the photo on the door leaf according to the sketches of the customer – digital printing
Sepia brown, close to RAL 8014
Select color
Desert Oak
Red brick

М-ribbed

  • 2 standard colors with Woodgrain embossing
  • 3 standard colors with smooth surface
  • 3 colors imitating wood grain with smooth surface
  • It is possible to paint in any colour according to RAL and DB catalogues.
  • 13 wood-finished colours - digital printing
  • 5 stone-finished colours - digital printing
  • Individual image of the photo on the door leaf according to the sketches of the customer – digital printing
Sepia brown, close to RAL 8014
Select color
Select color
Desert Oak
Red brick

L-ribbed

  • 2 standard colors with Woodgrain embossing
  • 4 standard colors with smooth surface
  • 3 colors imitating wood grain with smooth surface
  • It is possible to paint in any colour according to RAL and DB catalogues.
  • 13 wood-finished colours - digital printing
  • 5 stone-finished colours - digital printing
  • Individual image of the photo on the door leaf according to the sketches of the customer – digital printing
Sepia brown, close to RAL 8014
Select color
Select color
Desert Oak
Red brick

Cassette

  • 2 standard colors with Woodgrain embossing
  • 2 colors imitating wood grain with smooth surface
  • It is possible to paint in any colour according to RAL and DB catalogues.
  • 13 wood-finished colours - digital printing
  • 5 stone-finished colours - digital printing
  • Individual image of the photo on the door leaf according to the sketches of the customer – digital printing
Sepia brown, close to RAL 8014
Select color
Desert Oak
Red brick

Microwave S-ribbed М-ribbed L-ribbed Cassette
Woodgrain embossing Woodgrain embossing Smooth surface Woodgrain embossing Smooth surface Woodgrain embossing Smooth surface Woodgrain embossing
White (RAL 9016)
Sepia brown (RAL 8014)
Silver aluminum (RAL 9006)
Chocolate (RAL 8017)
Grey anthracite (RAL 7016)
Green moss (RAL 6005)
Gentian blue (RAL 5010)
Wine red (RAL 3004)
Light ivory (RAL 1015)
Anthracite (ADS 703)
Graphite (ADS704)
Golden oak
Dark oak
Cherry

Individual design of doors *

** Images are for illustrative purposes only

Brány Prestige sa vyrábajú s niekoľkými praktickými možnosťami:

prechodové dvere

Tento druh prechodových dverí sa objednáva,  ak majiteľ potrebuje ďalší vstup do priestorov. Jeho použitie umožňuje nielen vstúpiť do garáže bez otvárania brány, ale tiež ušetriť energiu. Táto možnosť vám umožňuje používať bránu s maximálnym komfortom.

V ponuke sú 3 varianty prechodových dverí:

So štandardným prahom 145 mm
(pre brány so šírkou od 4,5 do 6 m)

- samočinný zatvárač
- zabudovaný senzor polohy
- strieška pred dažďom
- spoľahlivé kovové úchyty
- špeciálné zariadenie ktoré vylučuje sadanie dverí.

S nízkym prahom 100 mm
(pre brány so šírkou do 4,5 m)

- samočinný zatvárač
- zabudovaný senzor polohy
- strieška pred dažďom
- spoľahlivé kovové úchyty
- špeciálné zariadenie ktoré vylučuje sadanie dverí.

S plochým prahom 20 mm
(pre brány so šírkou do 5 m)

- samočinný zatvárač
- zabudovaný senzor polohy
- strieška pred dažďom
- spoľahlivé kovové úchyty
- špeciálné zariadenie ktoré vylučuje sadanie dverí.

Orámovanie prechodových dverí sa vyberá z dvoch základných farieb - hnedá a strieborná. Alternatívne farebné riešenia sú vždy k dispozícii podľa katalógu RAL za príplatok.

Vstavané okná

Znížte spotrebu elektrickej energie a umožnite prístup k dennému svetlu - to sú úlohy, ktoré riešia vstavané okná. Tieto garážové brány budú okrem toho pripomínať svoj individuálny dizajn. Okrem toho okná sú súčasťou dekoratívneho ozdobenia brán.

Zámok

Ak chcete uzamknúť bránu v garáži bez ďalšieho vstupu, potrebujete zámok. K zámku je možné pripojiť zariadenie na odomknutie elektrického pohonu. Pri výpadku napájania pohonu brány je možnosť prepnúť na ručné ovládanie.

Bočné dvere

Predvolený štýl dverí je zjednotený s garážovými dverami. Vďaka rovnakému vzoru a farbe sa výrobok dokonale hodí do fasády každej budovy. Takže rovnaká farba a vzor vyzerajú ako jeden celok a harmonický zapadajú do fasady.

núdzove odomknutie

Pri automatizovaných bránach by sa malo zabezpečiť núdzové odblokovanie jednotky mimo garáže, napríklad v prípade výpadku elektrickej energie. Pohodlný a kompaktný odblokovací mechanizmus zaistí jednoduché prepnutie brány z automatického na ručné ovládanie.

Rozdiel medzi dizajnmi brán Prestige spôsobuje vyváženie dverného krídla.

S ťažnými pružinami

S torznými pružinami

Ťažné pružin Systém
vyvažovania
Torzné pružiny
45 mm hrúbka
sendvičového panelu
45 mm
Nerezová oceľ príslušenstvo
(valčekové konzoly a stredové pánty)
Nerezová oceľ
Šírka 3,500 mm, výška 3085 mm

rozmery brány (max)

Šírka 6000 mm, výška 3085 mm
100 mm
pre brány
bez elektrického pohonu
125-140 mm
pre automatické
brány
výška
prekladu (min)
100 mm
pre brány
bez elektrického pohonu
125-140 mm
pre automatické
brány
- typy
montážne
Nízka a štandardná
25 000 cyklov otvárania / zatvárania Základna životnosť 25 000 cyklov otvárania / zatvárania
